Dummy grade HEMT GaN Wafer for Power Application

university wafer substrates

HEMT Wafers for Power Applications

Gallium nitride is a wide bandgap semiconductor is the focus of much research and development in recent years due to its potential for high electron mobility transistors (HEMTs).

The promise of gallium nitride HEMTs is that they could offer a significant increase in performance over traditional silicon-based transistors, but the technology has yet to be perfected.

The solution: High electron mobility transistors based on gallium nitride could revolutionize the electronics industry, but significant challenges remain before this technology can be put into widespread use. UniversityWafer, Inc. and our parters are dedicated to overcoming these challenges and bringing this revolutionary technology to market. See below.

Researcher HEMT Request:

I’m looking for any of the various wafer types used in power, HEMT, and photonics, starting with GaN. I don’t need whole wafers, and could even use rejects, as I’d be hunting for crystal defects. I think my budget won’t allow more than a few hundred.

UniversityWafer, Inc. Quoted:

We usually using Silicon substrate epi growth the HEMT GaN wafer,Pls see below for the detailed spec and offer,our in stock HEMT GaN wafer was 6-inch wafer.

Dummy grade HEMT GaN Wafer for Power application

1. Substrate Silicon (111): 1000 μm thickness
2. Wafer diameter: 150 mm
3. Epi-Layer thickness: >/= 4.0 μm
4. "AlGaN (AlGaN barrier Thickness)": 25 nm
5. AIN spacer: 1 nm
6. GaN chanel: 300 nm
7. Surface morphology: Rms<0.5nm in 5×5 μm2
8. Wafer bowing: <50 μm
9. 2DEG ns tunable: >/= 1.0E13cm-2
10. Electron mobility: >/= 1600 cm2/Vs
11. Sheet resistance: > 360-ohm/s
12. Buffer resistivity: >105 Ohm.cm
13. Vertical Breakdown Voltage: >600V

$Conctact us

1 week delivery
