In the past decade, metal-oxide-semiconductor field-effect transistors (MOSFET) have been scaled down to increasingly smaller sizes. However, this has been difficult to continue due to limiting factors such as gate leakage current.
Replacing silicon dioxide with a high-k dielectric can increase gate capacitance and drive current, thus raising device performance. Many different oxides have been proposed to replace silica, but most of them have challenges such as electrical quality, thermodynamic stability, kinetic stability and process compatibility.
The gate dielectric is a crucial component in MOSFET field-effect transistors, providing the electric insulation
and capacitance necessary to perform electronic functions. Its performance is strongly influenced by its atomic structure and chemical composition. Metallic impurities contaminating the dielectric degrade its insulating and capacitive properties. Impurities also cause local reductions in the tunnel barrier and can induce traps that introduce a leakage path for charge carriers.
Maintaining the quality and reliability of gate oxide is one of the most challenging tasks in a semiconductor fab. In advanced CMOS technologies, the gate oxide thickness has shrunk to less than 30A thick — only about ten atomic layers — and its critical to maintain consistent quality across a twelve-inch wafer. With industry projections of further shrinkage of feature sizes, this trend will require the introduction of new gate dielectric materials that can meet demanding requirements.
Aluminum nitride (AlN) is a promising candidate for this purpose, with a lattice mismatch to SiC of only 1%, and nearly the same thermal expansion as silicon dioxide. In addition, it has a wider band gap energy than SiO2.
Another potential gate dielectric material is exfoliated h-BN, which offers a much higher breakdown voltage than traditional SiO2, and a bandgap close to that of the semiconductor. In the first demonstration of 2D materials-based n-channel organic field-effect transistors, exfoliated h-BN was used together with graphene, MoS2, and WSe2 as the working materials for the gate stack electrodes. This allowed for the fabrication of high-performance, low-power Ge n-channel MOSFETs with minimized off-state current leakage and on-to-off switching ratio.
In most cases the substrate used for a gate dielectric is silicon. However, there are other materials that are often used, such as boron nitride (h-BN), tungsten oxide (WO3), hafnium dioxide (HfO2), titanium oxide (TiO2) and aluminum oxide (AlO). For 2D material component devices, exfoliated h-BN is the choice of gate dielectric due to its combination of low dielectric constant and unique band structure (Bisi et al., 2018).
In the case of a MOS-C device, as the gate voltage increases the dynamic carrier generation and recombination moves toward net carrier generation. The positive gate voltage also attracts minority carriers at the substrate-to-oxide/well-to-oxide interface forming an inversion layer. Once this inversion layer reaches a critical depth, further increase of the gate voltage does not result in additional depletion of the semiconductor.
For this reason it is very important that the substrate has high reliability properties, such as thermal stability, process uniformity and defect morphology/density, especially in the presence of the gate dielectric. To achieve this, the underlying CMOS processes must be robust in the face of polishing microdamage and chemical oxidation damage (COP) as well as extended area defects such as epitaxial stacking faults. In addition, the atomic layer deposition (ALD) technology typically used in the industry is highly sensitive to the chemical composition of the underlying silicon substrate and the growth conditions.
The dielectric constant (k) is a property of the material that determines how much electric charge it can hold. Air has a dielectric constant of 1 while silicon dioxide, used as the gate oxide in old-fashioned CMOS transistors, has a k of about 3.9. The dielectric constant of a material affects the capacitance of a capacitor, but also how much it resists electric current. A low dielectric constant allows electrons to pass through the material more easily, while a high dielectric constant blocks them and limits their mobility.
The ideal gate dielectric should have a high enough dielectric constant to allow adequate current flow and be compatible with the process technology. It should also have a good thermal interface with the substrate to minimize carrier polarization and trapping at the metal/dielectric interface. The dielectric should also have a sufficiently wide band gap to allow sufficient electron mobilities for practical applications.
Hexagonal boron nitride (h-BN) has been proposed as an alternative gate dielectric to silicon dioxide due to its higher dielectric constant (k = 6.5), higher breakdown voltage (8-10 MV/cm), and narrower bandgap (6.3 eV). However, h-BN is a layered material that must be mechanically exfoliated or chemically synthesized at high temperatures. The Front End Processing (FEP) group will continue to evaluate new dielectrics that can meet these requirements, both in terms of process integration and device behavior.
The energy region that is unoccupied by electrons is called the band gap. If the material’s Fermi energy lies within this region, it is a semiconductor; if it is outside, it is an insulator.
There are some exceptions to this rule. Some materials that are insulators at normal temperatures may have small gaps in certain conditions, which can allow the transition of electrons between states. This phenomenon is known as a quantum tunneling effect.
In semiconductors, the gate dielectric can have a significant impact on the performance of the device. For example, in high-temperature operation, the generation and recombination of charge carriers at the dielectric interface can degrade the device’s performance.
For this reason, it is important to choose a gate dielectric with an appropriate band gap for the particular substrate in use. The energy position of the valence and conduction bands at the substrate surface can also play a role in the choice of gate dielectric.
For example, for 4H-SiC metal-oxide-semiconductor field-effect transistors (MOSFETs), the atomic layer deposition process of aluminum oxide (Al2O3) has demonstrated to be an excellent gate dielectric. This is due to the low work function of Al2O3, which can be tuned for both depletion and enhancement mode, as well as the relatively high energy position of the SiC valence and conduction bands with respect to the Al2O3 band gap (Kamimura et al., 2014).
Historically, silicon dioxide (SiO2) was the material of choice for the gate dielectric in silicon-based devices because of its excellent insulating properties and the ease with which it can be thermally grown on a silicon wafer. However, as devices have been scaled down in size to improve performance, the thickness of the gate dielectric has been reduced to the point where SiO2 is no longer effective at preventing leakage currents. Consequently, high-k dielectric materials (like hafnium oxide) have been introduced to replace or augment SiO2 in advanced devices. "High-k" refers to the high dielectric constant of these materials, which allows them to achieve the same capacitive effect as a much thinner layer of SiO2 but with reduced leakage.
